NYLON TUBE
- Material: PA12
- Fluid admitted: Air, water,oil,common solvents
- Service temperature range: From -40℃~120℃
- Features: The nylon tube(PA12) excels in resistance to abrasion and cracking, excellent resistance to solvents.
| NYLON TUBE LIST | |||||
|---|---|---|---|---|---|
| Specification | ID | OD | Length | Thickness | Working pressure |
| mm | mm | m | mm | MPa | |
| PA0425-100M | 2.5 | 4 | 100 | 1.5 | 3.2 |
| PA0402-100M | 2 | 4 | 100 | 1 | 4.5 |
| PA0503-100M | 3 | 5 | 100 | 1 | 3.4 |
| PA0604-100M | 4 | 6 | 100 | 1 | 3.2 |
| PA0806-100M | 6 | 8 | 100 | 1 | 2.8 |
| PA1008-100M | 8 | 10 | 100 | 1 | 2.7 |
| PA1007-100M | 7 | 10 | 100 | 1.25 | 2.6 |
| PA1210-100M | 10 | 12 | 100 | 1 | 3.2 |
| PA1209-100M | 9 | 12 | 100 | 1.5 | 2.8 |
| PA1208-100M | 8 | 12 | 100 | 2 | 2.8 |
| PA1410-100M | 10 | 14 | 50 | 2 | 2.5 |
| PA1411-100M | 11 | 14 | 50 | 1.5 | 2.2 |
| PA1512-100M | 12 | 15 | 50 | 1.5 | 2.0 |
| PA1612-100M | 12 | 16 | 50 | 2 | 2.8 |
| PA1815-100M | 15 | 18 | 50 | 1.5 | 2.3 |
| PA1814-100M | 14 | 18 | 50 | 2 | 2.4 |
Why Choose GUOWO Nylon Tube?
High quality material
PA12 we use is of high quality which has the feature of pressure resistance and low-temperature toughness.
Accurate dimension
The wall thickness , diameter and length accuracy is high.
Reliable quality
The testing of the nylon tube shows the smooth surface,low resistance and not easy to deform.And with high-temperature , acid-and alkali resistant.
On time Delivery
As rich experience and many kinds of specification of nylon tube, our delivery day is within 7 days.
FAQ
The PA12 nylon tube is widely used in vehicle, oil and gas,automation industry etc.
1.Hardness PA6 is higher than PA12. 2.PA6 working pressure is higher than PA12. 3.PA12 have performance of solvent and weather resistance better than PA6.
Yes, if there specification we do not have so far, could develop it , as more detail welcome to contact us.
